JIS G3459 SUS304 Stainless Steel Seamless Pipe Pickled And Annealed Surface

JIS G3459 SUS304 Stainless Steel Seamless Pipe Pickled and Annealed Surface

YUHONG GROUP deal with stainless steel welded pipe and tube already several decades, every year sell more than 5000 tons of stainless steel pipe and tube. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry, etc.

Standard Specification for JIS G3459

JIS G3459 is a JAPANESE industrial standard piping material. JIS G3459 pipes can be used in corrosion resistance for low temperature service and high temperature sevices. JIS G3459 Austenitic series stainless steel are available in various grade such as 304, 304H, 304L, 309, etc.

Equivalent Grade of SS 304 Pipe

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
304	S30400	304S31	58E	1.4301	X5CrNi18-10	2332	SUS 304

Grade	Solution Treatment ℃	Classification	Symbol of grade	Solution treatment ℃
SUS304TP	1010min. rapid cooling	Austenitic Pipe	SUS321TP	920min. rapid cooling
SUS304HTP	1040min. rapid cooling		SUS321HTP	Cold-finished 1095min. rapid cooling
SUS304LTP	1010min. rapid cooling		SUS321HTP	Hot-finished 1050min. rapid cooling
SUS309TP	1030min. rapid cooling		SUS347TP	980min. rapid cooling
SUS309STP	1030min. rapid cooling		SUS347HTP	Cold-finished 1095min. rapid cooling
SUS310TP	1030min. rapid cooling		SUS347HTP	Hot-finished 1050min. rapid cooling

JIS G3459 SS Pipe Mechanical Properties

Grade	Tensile strength N/m㎡	Proof stress N/mm²	Elongation %
			No. 11 test piece No. 12 test piece	No.5 test piece	No.4 test piece
			Longitudinal direction	Transverse direction	Longitudinal direction	Transverse direction
SUS304TP	520min	205min	35min	25min	30min	22min
SUS304HTP	520min	205min	35min	25min	30min	22min
SUS304LTP	480min	175min	35min	25min	30min	22min
SUS309TP	520min	205min	35min	25min	30min	22min
SUS309STP	520min	205min	35min	25min	30min	22min
SUS310TP	520min	205min	35min	25min	30min	22min
SUS310STP	520min	205min	35min	25min	30min	22min

JIS G3459 SS Pipe Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Ni
SUS304TP	0.08max	2max	1max	0.045max	0.03max	18-20	8-11
SUS304HTP	0.04-0.1	2max	0.75max	0.04max	0.03max	18-20	8-11
SUS304LTP	0.03max	2max	1max	0.045max	0.03max	18-20	9-13
SUS309TP	0.15max	2max	1max	0.04max	0.03max	22-24	12-15
SUS309STP	0.08max	2max	1max	0.045max	0.03max	22-24	12-15
SUS310TP	0.15max	2max	1.5max	0.04max	0.03max	24-26	19-22
SUS310STP	0.08max	2max	1.5max	0.045max	0.03max	24-26	19-22

Applications

1.Industrial hydraulic
2.Automobile industry
3.Industrial machinery industry
4.Industrial automation
5.Rail transit
6.Heat exchange
7.Decoration works
8.Other
