Titanium Tube SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6 Heat Exchanger Tube Industial and Medical Application

Ask Lasest Price
Brand Name :	YUHONG
Model Number :	SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6
Certification :	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	1000Ton per month
Delivery Time :	35-40 DAYS

Add to Cart

Product Details
Company Profile

Titanium Tube SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6 Heat Exchanger Tube Industial and Medical Application

Titanium Tube SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6 Heat Exchanger Tube Industial and Medical Application

Titanium Round Tubes is recognized for having a high strength to weight ratio. titanium NCF Tubes are considered to be a strong alloy with low density. Additionally, the titanium alloy tubing is quite ductile. The titanium tubing material is paramagnetic in nature. As compared to other metals, titanium alloy tube has a fairly low electrical and thermal conductivity.

Item	Titanium Tube / Titanium Pipe
Standard	ASTM B861-05,ASTM B862-05,ASTM B338-06,GB/T3625-2007, GB/T3624-2007,JISH4630-2001,JISH4631-2009,etc
Material	TA1,Gr.1,TP270H,BT1-00,TA2,TP340H,Gr.2,BT1-0,Ti2,TA3,Gr.3, TP480H,Ti3,TA9,Gr.7,TA10,Gr.12,etc
Size	OD:2-910mm WT:0.2-100mm Length:1-10m,or as reqired
Package	Standard export package,suit for air and sea transport,by wooden box or as required
Price term	Ex-Work,FOB,CNF,CFR,CIF,etc
Export to	Poland ,India,Singapore,Indonesia,Dubai,Ukraine,Saudi Arabia,Spain, Brazil,Korea,Thailand,USA,UK,Canada,Ireland,etc
MOQ	100Kg
Application	Because of the titanium excellent corrosion resistance, titanium material widely used in petroleum,chemical,salt,Pharmaceutical, metallurgy,electronic,aviation, aerospace, Marine,etc.
Contact	If you have any question,please feel free to contact us . We are sure your inquiry or requirements will get prompt attention.

Titanium Seamless Tube Specification

Dimension	Outer Diameter	Thickness	Length
Size Range:	0.5mm – 330mm	0.4mm – 10mm	Max 15m
Manufacturing Standards	ASTM B338, ASTM B861, DIN 17 861

Titanium tube Chemical requirements

	Tensile strength		Yeild strength min max		Elongation
	MPa	kis	ksi Mpa	ksi Mpa	%
Gr 1	240	35	20(138)	45(310)	24
Gr 2	345	50	40(275)	65(450)	20
Gr 3	450	65	55(380)	80(550)	18
Gr 7	345	50	40(275)	65(450)	20
Gr 9	620	90	70(483)	...	15
Gr11	240	35	20(138)	45(310)	24
Gr12	483	70	50(345)	...	18
Gr13	275	40	25(170)	...	24
Gr14	410	60	40(275)	...	20

Titanium Seamles Tubes Surface Finish

Surface Finish		Internal Surface(ID)		Exterbal Surface(OD)
		Roughness Average(RA)		Roughness Average(RA)
		μ inch	μm	μ inch	μm
MP	Mechanical Polish	40,32,25,20	1.0,0.8,0.6,0.5	32	0.8
EP	Electro Polish	15,10,7,5	0.38,0.25,0.20;0.13	32	0.8
BA	Beight Annealed	40,32,25,20	1.0,0.8,0.6,0.5	32	0.8
AP	Annealed & Pickled	Not defined	Not defined	40 or Not defined	1.0 or Not defined

Features of Titanium Oval Tubing

Great strength
Sturdy construction
Dimensional accuracy
Corrosion resistance
Durability
Effective functionality

Titanium Tube Application

Welded or Seamless tube for other fabricated pipe spools
Seamless Titanium Grade 2 Tube for Heat Exchangers.
Tube for bicycles, golf clubs and other sporting items, condensers, instrumentation.
Welded Titanium Grade 1 or 2 tube for an exhaust system in your performance street or racing car.
Welded or Seamless Pipe for HPAL plants in Titanium Grade 2 or Titanium Grade 12
Forgings, Fittings and Flanges are also available in most grades of Titanium.
