| Specifications | Super Duplex 2507 Flanges |
|---|
| Super Duplex Flanges Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10,
EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges,
EN Flanges, GOST Flanges. |
|---|
| ASME B16.5 Super Duplex Flange size range | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 |
|---|
| Super Duplex Flange Standard DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
|---|
| Super Duplex Flange Standard ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
|---|
| Super Duplex Flange Standard UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
|---|
| Super Duplex Flange Standard EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
|---|
| Super Duplex Flange Standard JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
|---|
| Main Types | Forged / Threaded / Screwed / Plate |
|---|
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
|---|
| Most common types of Super Duplex Flanges | - Socket Weld Ring Flange (SWRF), Super Duplex
- Threaded Ring Flange, Super Duplex
- Blind Ring Flange (BLRF), Super Duplex
- Weld Neck Ring Flange (WNRF), Super Duplex
- Slip-On Ring Flange (SORF), Super Duplex
- Ring Type Joint Flange (RTJF), Super Duplex
- Lap Joint Ring Flange (LJRF), Super Duplex
|
|---|
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large
Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF),
Small Tongue, Large Tongue & Groove, , Groove |
|---|
| Super Duplex Pipe Flanges Test Certificates | EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc |
|---|
| Production technique | - Forged, Heat treated and machined
|
|---|
| Special design | As per your drawing
AS, ANSI, BS, DIN and JIS
15 NB (1/2") to 200 NB (8")
Equal and Reducing Configurations
Super Duplex Threaded Flange, Socketweld Flange, Slip-On Flange,
Blind Flange, Weld Neck Flange |
|---|
| Specialized manufacturer of | - DIN 2566 en 1092 1
- Pn16 Flange
- DIN 2566 pn16
- Rtj Flange
- Super Duplex Sorf Flange
- Super Duplex Table Flanges
- DIN 2566 pn10
- Super Duplex Large Diameter Flange
- Super Duplex Threaded Flanges
- Super Duplex Blind Flanges
- Super Duplex Plate Flanges
- Super Duplex Weld Neck Flanges
- Super Duplex Loose Flanges
- Super Duplex Orifice Flanges
- Super Duplex Slip-On Flanges
- Super Duplex Lap Joint Flanges
- Super Duplex Socketweld Flanges
- Super Duplex AS 4087 Water Flanges
|
|---|
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI
trasonic flaw detector, X-ray detector, Magnetic particle detector |
|---|
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing
Machine, Sand-blasting machine etc |
|---|
| Origin | West Europe /Indian / USA / Japan / Korean |
|---|
| Super Duplex 2507 Flanges Standard | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc.
BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN
Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange,
GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange - AS 2129: Table D; Table E; Table H
- B.S: BS4504 , BS3293, BS1560, BS10
- ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI
B16.48
- ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA,
Custom Drawings
- American standard (ANSI)
- ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
- British standard (BS)
- German (DIN)
- Any other specilised flanges
- The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS
B1503, SABS1123; NFE29203;UNI2276
- DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642,
DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN
2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638
|
|---|
| Key markets and industries for Super Duplex Flanges | - Nuclear power (mostly seamless).
- Heavy oil refineries.
- Bitumen upgraders.
- Petrochemicals and acids.
|
|---|
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru,
Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain,
Oman etc |
|---|
| Super Duplex 2507 Flanges Application | - To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical,
Gas, Shipbuilding,Metallurgy, etc
|
|---|
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204
3.2, Test Certificates certifying NACE MR0103, NACE MR0175 |
|---|
