ASME SA213 TP316L Straight Tube bundle in Shell and Tube Heat Exchanger

Ask Lasest Price
Brand Name :	YUHONG
Model Number :	TUBE BUNDLE, TUBESHEET
Certification :	ASME, ASTM, ASME U Stamp
Price :	0-1000000USD
Payment Terms :	T/T, L/C, D/A
Supply Ability :	15 SETS/MONTH
Delivery Time :	30-60DAYS

Add to Cart

Product Details
Company Profile

ASME SA213 TP316L Straight Tube bundle in Shell and Tube Heat Exchanger

ASME SA213 TP316L Straight Tube bundle in Shell and Tube Heat Exchanger

We specialize in manufacturing Shell & Tube Heat Exchangers, Oil Coolers, Steam Heaters, Air Preheaters, Finned Tube Coolers, Finned Tube Heaters, Cooling Towers, Cooling Equipment, Condensers, Air Receivers, Blast Furnace Oil Coolers, Hot Air Generators, Industrial Heat Exchangers, Evaporators, Heat Exchanger Coils, Radiators, Pressure Vessels, Wound Finned Tubes/Coolers, Extruded Finned Tubes, Rectangular/Square finned tubes, and all other heat transfer products.

YUHONG GROUP Heat Exhanger Tube bundle parts- 081-E-0001 A/B/C
NO.	POS	DESPRITION	SIZE	MATERIAL	OVERLAY CLADDING	QUANTITY
A	A--0	Seamless TUBE	Ø19.05×2.11(min) x7315mm	ASME SA213 TP316L	/	2490	PCS
11	3-1	S.T. TUBE SHEET	Ø997×81mmT	SA350 LF2 CL1N	8MM SS316L	3	PC
12	3-2	F.L. TUBE SHEET	Ø926×81mmT	SA350 LF2 CL1N	8MM SS316L	3	PC
17	4-5	GASKET	Ø926×4mmT	SS316L+GRAPHITE	/	9	PCS
21	5-4	STUD B./2H.N	1-8UNC×395L	SA320-L7/SA194-2H	/	108	PCS
22	5-5	SQ. STUD B./2H.N	1-8UNC×445L	SA320-L7/SA194-2H	/	33	PCS
27	7-1	F.T H.D FLANGE	Ø1026×Ø894×100mmT	SA350 LF2 CL1N	3MM SS316L	3	PC
28	7-2	F.T H.D COVER	Ø894×25mmT	SA516 GR.70N	3MM SS316L	3	PC
29	7-3	BACKING RING	Ø1026×Ø894×167mmT	SA350 LF2 CL1N	/	3	PC
32	10	CONNECTION PIECES	Ø1018×Ø914×27mT	SA516 GR.70N	/	6	PCS
33	1-1	BAFFLE	Ø935.2×649.2×10mmT	SA516 GR.70N	/	3	PC
34	1-2	BAFFLE	Ø935.2×649.2×8mmT	SA516 GR.70N	/	21	PCS
35	1-3	BAFFLE	Ø935.2×649.2×10mmT	SA516 GR.70N	/	3	PC
36	1-4	BAFFLE	Ø935.2×649.2×8mmT	SA516 GR.70N	/	21	PCS
37	1-5	SUPPORT PLATE	Ø935.2×16mmT	SA516 GR.70N	/	3	PC
38	3	TIE ROD / NUTS	Ø13×6869mmL	SA36/194-2H	/	24	PCS
39	4-1	SEALING STRIP	8×27×5579mmL	SA516 GR.70N	/	12	PCS
40	4-2	SEALING STRIP	8×56.5×5579mmL	SA516 GR.70N	/	6	PCS
41	5	SLIDING SHOE	16×41×6843mmL	SA516 GR.70N	/	6	PCS
42	6	IMPINGEMENT PLATE	T=12mm	SA516 GR.70N	/	3	PC
43	7-1	LIFTING LUG	16×80×190	SA516 GR.70N	/	6	PCS
44	7-2	LIFTING LUG	16×80×190	SA516 GR.70N	/	6	PCS
45	7-3	LIFTING LUG	16×80×140	SA516 GR.70N	/	9	PCS
46	7-4	LIFTING LUG	16×95×170	SA516 GR.70N	/	12	PCS
47	7-5	LIFTING LUG	25×110×160	SA516 GR.70N	/	12	PCS
48	7-6	LIFTING LUG	T=25mm	SA516 GR.70	/	12	PCS
49	7-7	RIB PLATE	T=25mm	SA516 GR.70	/	12	PCS
50	7-8	REINFORANCE PAD	T=14mm	SA516 GR.70	/	12	PCS
51	9-1	EYE BOLT	M36×P4	SA36	/	12	PCS
52	9-2	PLUG	M36×P4×75	SS304	/	12	PCS
53	10	CENTERING PIN LUG	T=25mm	SA516 GR.70	/	6	PCS
A	HEAT TREATMENT
B	HYDROSTATIC TEST
A	HARDNESS TEST
B	MECHANICAL PROPERTY
A	CHEMICAL ANALYSIS REPORT
B	WELDING PROCEDURE SPECIFICATIONS

The main benefits of cooperating with Yuhong Group

Prioritising customer satisfaction and delivering high quality heat exchangers.

Yuhong Group considers various factors such as performance, environment, ety, material selection, maintenance and service life.

With experienced and skilled engineers, we provide the best solutions to meet customer needs.
